高精度，铝合金材质，OIML R60 C3-C5认证，被广泛应用于计价秤，计数秤，计量秤等，最大秤盘尺寸为250*350mm.

         High precision, aluminum alloy material, OIML R60 C3-C5 certification, is widely used in pricing scales, counting scales, measuring scales, etc., the maximum weighing pan size is 250*350mm.

额度量程 Rated Capacity-------3,6,10,15,20,30,40,50

(kg)

精度等级 Accuracy Class--------G*

灵敏度 Sensitivity----------2.0±10%mV/V

零点输出 Zero Balance-----------±5%R.0.

输入电阻 Input Resistance-------405±10

输出电阻 Output Resistance-----350±3

非线性误差 Linearity Error--------±0.015%R.0.

重复性误差 Repeatability Error---±0.01%R.0.

滞后误差 Hysteresis Error----------±0.01%R.0.

30分钟蠕变 Creep in 30 Min.-------±0.02%R.O.

输出温度影响 Temp.Effect on Output--±0.02%R.0./10°C

零点温度影响 Temp.Effect on Zero-----±0.02%R.0./10°C

温度补偿范围 Compensated Temp.Range---10-+40℃

推荐激励电压 Excitation,Recommended-------5 -12VDC

最大激励电压 Excitation,Maximum----------------18VDC

工作温度范围 Operating Temp.Range---------20-+60°C

安全过载范围 Safe Overload---------------------150%R.C.

极限过载范围 Ultimate Overload---------------200%R.C.

绝缘电阻 Insulation Resistance------≥5000MQ(50VDC)

电缆线长度 Cable,Length--------05mmx1.5m *

防护等级 Protection Class--------IP65
