本产品具有较高的性能和稳定性,抗过载、偏载能力强:采用不锈钢、合金钢波纹管焊接密封,可承受拉压两种受力型式:适用于各类包装秤,配料秤,皮带秤等称重系统。

        This production has advantage in stability, against excess loadingand side loading. Sealed by stainless steel or Alloy steel cockles pipe,can bear from press and pulling.It can be used in packing scale,batching scale, strap scale and other weighing system.

额度量程 Rated Capacity-------10-1000(Kg)

精度等级 Accuracy Class--------C3

灵敏度 Sensitivity----------2.0±0.002%mV/V

零点输出 Zero Balance-----------±0.1mV/V

输入电阻 Input Resistance-------400±10

输出电阻 Output Resistance------350±2

非线性误差 Linearity Error--------±0.05%R.0.

重复性误差 Repeatability Error---±0.05%R.0.

滞后误差 Hysteresis Error----------±0.05%R.0.

30分钟蠕变 Creep in 30 Min.-------±0.05%R.O.

输出温度影响 Temp.Effect on Output--±0.05%R.0./10°C

零点温度影响 Temp.Effect on Zero-----±2%R.0./10°C

温度补偿范围 Compensated Temp.Range---10-+40℃

推荐激励电压 Excitation,Recommended-------5 -12VDC

最大激励电压 Excitation,Maximum----------------18VDC

工作温度范围 Operating Temp.Range---------30-+70°C

安全过载范围 Safe Overload---------------------150%R.C.

极限过载范围 Ultimate Overload---------------200%R.C.

绝缘电阻 Insulation Resistance------≥5000MQ(50VDC)

电缆线长度 Cable,Length--------05mmx1.5m *

防护等级 Protection Class--------IP65
