本产品采用支脚、不倒翁、上下压头等组件，安装方便，适用于单双层台面的电子平台秤等称重系统。

     Combined with support or tumble or pressure head subassembly,Easy installation, it's suitable for single electronic platform scale and other weighing system.

额度量程 Rated Capacity-------10-1000(Kg)

精度等级 Accuracy Class--------C3

灵敏度 Sensitivity----------2.0±0.002%mV/V

零点输出 Zero Balance-----------±0.1mV/V

输入电阻 Input Resistance-------400±10

输出电阻 Output Resistance------350±2

非线性误差 Linearity Error--------±0.05%R.0.

重复性误差 Repeatability Error---±0.05%R.0.

滞后误差 Hysteresis Error----------±0.05%R.0.

30分钟蠕变 Creep in 30 Min.-------±0.05%R.O.

输出温度影响 Temp.Effect on Output--±0.05%R.0./10°C

零点温度影响 Temp.Effect on Zero-----±2%R.0./10°C

温度补偿范围 Compensated Temp.Range---10-+40℃

推荐激励电压 Excitation,Recommended-------5 -12VDC

最大激励电压 Excitation,Maximum----------------18VDC

工作温度范围 Operating Temp.Range---------30-+70°C

安全过载范围 Safe Overload---------------------150%R.C.

极限过载范围 Ultimate Overload---------------200%R.C.

绝缘电阻 Insulation Resistance------≥5000MQ(50VDC)

电缆线长度 Cable,Length--------05mmx1.5m *

防护等级 Protection Class--------IP65
